TianYing is the most innovative made of mature, leading and advanced 5km~50km 1Hz~20Hz laser rangefinder, 20mJ~400mJ laser designator rangefinder, accuracy measuring tracking systems, 300mm~2000mm focal length no chromatic aberration coaxial zoom spotter SWIR NIR CCTV camera sights, electro-optical targeting systems, telephoto thermal cameras etc.
China TianYing SHD600 18km tank surveillance 8MP 10~600mm zoom no chromatic aberration CCTV camera is the leading low cost long range 4K crisp sharp visual optronic sensor for monitoring platforms.
The camera features a compact, domestic, digital, presetting, specified focal length, coplanar design, wide spectrum, concise, integration, 8MP 1/1.8" 2μm sensor and 10~600mm continuous zoom pure optical lens.
Mounted on a monitoring platform, this stable reliable operating network camera captures true 4K crisp sharp broadcast images of high color saturation with extraordinary accuracy simultaneously.
Use its recognition distance equivalent to a full HD 1/1.8-inch 3.75μm f8.8 1125mm focal length camera, this true 4K broadcast imagery camera delivers unparalleled reasonable cost. In addition, optional 2pixels precision coaxial zoom is available for aligning targets of tactical platforms.
Comparative advantage features: 1. 4K no chromatic aberration crisp sharp clean broadcast imagery, inclduing the edge of the telephoto;
2. Option precision long and short focal coaxial zoom or high precision 2 pixels deviation;
6. Large depth of field in long focal length, focus coplanar design, wide spectrum, fast smooth zoom with stable real-time image and no image blackout;
7. Operates from -30 degrees to +60 degrees without heating;
8. Ultra-small size, ultra-light weight, Swiss motor level life and ultra-high impact resistance intensity;
9. Match the recognition range of full HD 1/1.8" 1200mm f9 lens TV, deliver unmatched affordable cost;
4K 8MP 1/1.8" 10~600mm zoom surveillance security CCTV camera specifications:
Model
SHD600
Sensor
Effective sensor size
1/1.8 inch (2 microns)
Effective Pixels
> 8 Megapixel
Resolution
3840 x 2160 pixels
Frame Rate
25Hz/30Hz.
Signal to noise ratio
≥50dB (AGC OFF), option ≥90dB
Electronic Shutter Speed
1/3～1/100,000s
Coding format
H.265/H.264/MJPEG
Video bit rate
H.264：8Kbps ~ 16384Kbps, H.265：3Kbps ~ 14050Kbps
Min. Illumination
Color: 0.001Lux; B/W: 0.0001Lux;
Day/Night
Auto/Manual
White Balance
Automatic, natural light, street lamps,outdoors,manual, area customization
Image enhancement
Electronic defog, super wide dynamic, electronic image stabilization, strong light suppression, back light correction, 3D Noise Reduction etc
Plug-ins: Internet Explorer 8 and above /chrome45 and below /firefox46 and below /safari12 and below;
None: Edge/ chrome45 or later /firefox46 or later /safari12 or later
Preview maximum number of users
20 PCS (total bandwidth: 320M)
Image Control
Control interface
RS422/RS485
Environmental Adaptability
Operating Temperature(no heater)
-30°C to +60°C, option -40°C to +60°C
Working humidity
≤ 95%
Impact resistance and shock-proof (G)
Meet relevant standard
Physical
Dimensions without house
Approx 6350 cubic centimeters.
Weight without house
Approx 4.6kg
Packing and Warranty
Standarding accessories packing
hard case, user's manual, video cable, power cable
Warranty
1 year warranty and free lifetime maintenance.
Note: *- Technical information is subject to change without notice. ** -Depending on the region of sale.
*** - Option add normal house and sealing house.
Product Image
18km tank surveillance 4K 10~600mm zoom no color aberration CCTV camera
18km tank surveillance 4K 8MP 1/1.8 inch 10~600mm zoom no color aberration IR CCTV camera see 50m wall at 600mm focal length
18km tank surveillance 4K 8MP 1/1.8inch 10~600mm zoom no color aberration IR CCTV camera see 50m wall at 10mm focal length
18km tank surveillance 4K 8MP 1/1.8 inch 10~600mm zoom no color aberration CCTV camera see 850m building at 600mm focal length
18km tank surveillance 4K 8MP 1/1.2 inch 2.9μm 10~600mm zoom no color aberration CCTV camera see 2km tower crane at 600mm focal length
18km tank surveillance 4K 8MP 1/1.2 inch 2.9μm 10~600mm zoom no color aberration CCTV camera see 6km rock and light pole at 600mm focal length
SHD600 4K 8MP 10~600mm Zoom no chromatic aberration NIR CCTV Camera see 850m-1km building and 50m wall
High accurate coaxial zoom defog surveillance security CCTV camera align target
