China TianYing HD500-LAN 25km lighthouse surveillance security 2MP 16~500mm EO coaxial zoom no chromatic aberration IR CCTV camera is the world's leading visual optronic sensor, engineered to aim and align targets instantly when seen, specifically use in an airborne, marine and land tactical platforms.
Only a compact EO camera replaces traditional continuous zoom, spotter, multi-spectral, HD no chromatic aberration color, NIR, low light and supper defog all TVS. Ruggedly built and sized to leave a tiny footprint, it stands up to harsh environmental conditions and fits into the most tightly constrained spaces.
The camera features a compact, domestic, digital, multiple AI technologies intelligent, presetting, multi-schema database, concise, integration, focus coplanar design, wide spectrum, global exposure 2MP 1/1.8-inch sensor and 16.7~500mm continuous coaxial zoom pure optical lens.
Mounted on a stabilized platform, this high-performance camera captures crisp sharp images of high color saturation and aligns targets with extraordinary accuracy simultaneously.
1. Measuring aim.
2. Weapon sight.
4. Target tracking.
6. Precision aerial photo and surveillance of crisp sharp images with high color saturation.
Comparative advantage features:
1. No chromatic aberration design, the edge of the telephoto image is sharp, clean and complete;
2. High precision long and short focal coaxial zoom;
3. No jumping during zooming;
4. Multiple AI technologies intelligent, multi-schema database, 3x supper defog ability and better effect;
5. Datalization: real-time data backhaul, focal length preset, focusing preset, specify focal length etc;
6. Operates from -40 degrees to +60 degrees without temperature compensation and without heating;
7. Crisp sharp images of high color saturation is conducive to the detection of long range and small targets, and multiplication of recognition ability;
8. Large depth of field in long focal length, fast smooth zoom with stable real-time image and no image blackout;
9. Ultra-small size, ultra-light weight, Swiss motor level life and ultra-high impact resistance intensity.
2MP 16~500mm coaxial zoom no chromatic aberration surveillance CCTV camera specifications:
||Approx 25km for lighthouse, Approx 30km for plane
||Approx 16km for lighthouse, Approx 20km for plane
|Effective sensor size
||Global exposure micron
||> 2 Megapixel
||1920 x 1080 pixels
|Signal to noise ratio
||≥50dB (AGC OFF), option ≥90dB
||400nm ~ 1100nm (0.4~0.7μm daylight, 0.7μm~1.1μm NIR)
|Field of View (3.45um-SDI),°
||Approx 22.7° x 12.7° ~ 0.75° x 0.42°
|Field of View (3.75um-LAN),°
||Approx 24.7° x 13.8° ~ 0.82° x 0.46°
||16.7mm~500mm continuous optical zoom.
|Close-up distance, m
||Quick automatic with no shift, including switching mode
|No chromatic aberration
||10-20pixels deviation, option 1 pixel and ≤ 3 pixel, typical 2 pixel
|Large depth of field in long focal length
|Coplanar visible light and infrared
||Yes, including short focal length and long focal length
|Rear focal adjustment
|Real-time data backhaul
||focal length preset, focusing preset,specify focal length position etc
||Data backhaul, preset bit, focusing bit, specify focal length etc
||Multi-schema database, 3x optics filter IR supper defog etc
||Swiss motor level
|Optical zoom time + focus time
||Approx 8 seconds with basically real-time focus
||electric zoom, electric/auto focus, electric/auto optical filter
|Input / Output
||HDSDI/EXSDI digital, CVBS analog;
||Option LAN network video: RJ45 H.265/H.264/MJPEG, BNC
|Operating Temperature( no heater)
||-40°C to +60°C , temperature shock 5°/min
||-50ºC to +70ºC
|Impact resistance and shock-proof (G)
||Meet relevant standard, up to ultra-high impact resistance
|Dimensions without house
||Approx 2086 cubic centimeters.
|Weight without house
|Packing and Warranty
|Standarding accessories packing
|| hard case, user's manual, details test report, video cable, power cable
||1 year warranty and free lifetime maintenance.
|Note: *- Technical information is subject to change without notice. ** -Depending on the region of sale.
*** - Option add normal house and sealing house.
1, Why normal telehoto CCTV camera can not see human 10km? such as telehoto 1000mm, 1200mm etc.
Because their focal length data is not real, their focal length is not pure optics, their lens diameter is too small, their telephoto image is not clear, or their defog is bad;
Such as 1200mm is only 1000mm real focal length, then plus 2x extender said 2400mm focal length, even 770mm-800mm is only 400mm real focal length.
When telephoto image is clear, sharp and crisp with with high color saturation, then, discernment will be multiplied; also, normal long range have fog, especially the sea and the jungle.
2, Why the 2MP camera image is better than some 8MP and even 8K camera?
Because the camera is no chromatic aberration design that image is clear and sharp with high color saturation, including telephoto edge image.
3, Why many 750mm/ 1000mm/ 1200mm focal length CCTV surveillance camera is only used for 3km-5km laser rangefinder?
Because their optical axis can not align target, such as 2mrad accuracy is 2m for 1000m distance and 6m for 3000m distance.
then their camera can not shoot 3km vehicle, so their laser rangefinder task is only roughly measurement.
4, Why the 2MP camera price is much higher than normal CCTV camera?
Because the camera is coaxial zoom with no chromatic aberration, rapid auto, supper defog, wide spectrum, shockproof, compact size and ultra-long life, also image quality can compete with some SLR camera.
