China TianYing SW500 ultra-compact precision EO coaxial zoom spotter SWIR camera is designed for high accuracy long range surveillance and tracking in mobile systems or field installations, delivered in a ruggedized package and it is equipped with a high resolution, InGaAs 640 x 512 pixels, 15μm pitch focal plane array operating in the 0.9 – 1.7 microns waveband.
The SW500 can be query and real time backaul zoom position information, query and real time backaul focus position information, the RS-232/422 remote control capability permits ease of integration into any client-based security system.
TianYing provides leading-edge visble light and IR equipment to the security and surveillance sector. TianYing’s proprietary optical designs, state-of-the-art techniques, ensure maximum performance and dependability.
Main features:
1.High precision long and short focal coaxial zoom;
2. Focus maintained while zooming;
3. Unique zoom module with zero optical artifacts;
4. Real time backaul zoom position and focal length position;
5. Ultra-small size;
6. Operates from -40 degrees to +60 degrees;
Best 640X512 17~500mm coaxial continuous zoom spotter surveillance SWIR camera specifications:
| Model |
SW500(SD 15um) |
SW500(SD 5um) |
SW500(HD 5um) |
| Performance |
| Detection human |
Typical 5km |
Approx 9km, even 13km |
| to 6m x 3m vehicle/boat |
Approx 20km |
Approx 30km |
| Recognition human |
Typical 3km |
Approx 6km |
| to 6m x 3m vehicle/boat |
Typical 10km |
Approx 15km |
| Sensor |
| FPA Material |
InGaAs |
|
| Resolution |
640x512 |
640x512 |
1280x1024 |
| |
Option 1920x1080 / 2592x2056 3.45um /8mp resolution sensor |
| Wavelength range |
900nm ~ 1700nm |
400nm ~ 1700nm |
400nm ~ 1700nm |
| Frame Rate |
25Hz/30Hz |
| Signal to noise ratio |
≥50dB |
| Optics |
| Focal Length |
17~500mm continuous optical zoom |
| Aperture |
F6~F10.8 |
| Field of View |
32.3°x25.8°~1.1°x 0.8° |
10.7°x8.6°~0.36 x0.29° |
21.5° x 17.2~ 0.73°x0.58° |
| Focus |
Electric / automatic |
Electric, option automatic |
| Option through-zoom boresight |
≤ 3 pixel, typical 2 pixel, option 1 pixel and 10-20pixels deviation |
| Rear focal adjustment |
Electric |
|
|
| Real-time data backhaul |
Zoom position, specify focal length position |
| Motor life |
Swiss motor level |
|
|
| Lens control |
electric zoom, electric/auto focus, fixed IRIS |
| Input / Output |
| Power supply |
DC12 ±10% |
DC12 ±10% |
| Video output |
CVBS analog, |
2.5GigE (RJ45 H.265/H.264) |
| |
Option cameralink; |
Option SDI / cameralink |
| Image Control |
| Control interface |
RS422 |
| Environmental Adaptability |
| Operating Temperature |
-40°C to +60°C |
-40°C to +60°C(heater) |
| Storage Temperature |
-50ºC to +70ºC |
| Impact resistance and shock-proof |
Meet relevant standard, up to ultra-high impact resistance |
| Physical |
| Dimensions without house |
Approx 2086 cubic centimeters. |
|
| Weight without house |
Approx 2kg |
|
|
| Option |
| Option laser rangefinder |
such as ≥ 6.6km of 30cm x 8cm 0.024m² drone |
|
| Option pan tilt |
±0.01° shot recall repeatability(mechanical backlash+electric) |
| |
Resolution < 0.00055°(< 2 arcses), min angular feedback accuracy |
| |
with top or middle load mode |
| Packing and Warranty |
| Standarding accessories packing |
hard case, user's manual, details test report, video/power cable kit |
| Warranty |
1 year warranty and free lifetime maintenance |
Note:*- Technical information is subject to change without notice. ** -Depending on the region of sale.
*** - Option add sealing house. |
