| Model |
TY-P15 |
| Performance |
| Daytime |
≥12km (can be 14km) for human |
| Night |
≥2km (can be 3km, even over 3km) for human |
| Identify the person's face |
Approx 1.6km |
| Read the driving license plate |
Approx 1.6km |
| Day Night TV Camera |
| Sensor |
1/1.8 inch COMS 4 Megapixel 2688 x 1520 25Hz/30Hz. |
| Signal to noise ratio |
≥55dB (AGC OFF) |
| Coding format |
H.265 / H.264，H.265+/H.264+, HDMI/SDI/CVBS/RJ45 |
| Video bit rate |
32kbps~32Mbps |
| Storage Capabilities |
Micro SD/SDHC /SDXC card (256 GB) |
| Network Protocol |
ONVIF, HTTP, RTSP, RTP, TCP, UDP etc |
| Min. Illumination |
Color: 0.005Lux f1.5; B/W: 0.001Lux f1.5 |
| Image adjustment |
Brightness, contrast, saturation, sharpness, chroma etc |
| Image enhancement |
Strong light suppression, Exposure mode, BLC, ROI, 3D NR etc |
| Wavelength range |
400nm ~ 950nm (0.4~0.7μm daylight, 0.7μm~0.95μm NIR) |
| Field of View (2.9um-LAN),° |
Approx 35.7° x 20.2° ~ 0.59° x 0.33° |
| Focal Length |
12.5~750mm continuous optical zoom. |
| Aperture |
F6~ F11 |
| Close-up distance, m |
Approx 5m(can be 1m) |
| Image stabilization |
Support |
| Electronic defog |
automatic, manual, manual mode defog level can be adjusted |
| Optics defog |
Support |
| Serial command |
Support rear focal adjustment, specify focal length etc function |
| AI detection and alarm |
Support area intrusion, cross-border,sound detection, behavior analysis etc |
| AI recognition |
Can accurately identify human figures, vehicles and other targets |
| Operating temperature |
-25ºC ~ +60ºC |
| Laser Illuminator |
| Wavelength |
808nm |
| Power |
25W |
| Light source change mode |
Laser and lens angle linkage, manual |
| Homogenization balanced light |
Yes |
| Operating temperature |
-40ºC ~ +35ºC |
| Pan/Tilt |
| Random error of angular accuracy |
0.1° |
| Direction range |
azimuth:360° continuous; elevation:+10°~-70° |
| Directing speed range for azimuth |
0.01°/s to 15°/s |
| Directing speed range for elevation |
0.01°/s to 15°/s |
| Presets |
200 presets, supporting zoom focus presets memory |
| Cruise |
4 cruising paths, each path can set 16 presets |
| Communication protocol |
Pelco-D |
| Operating temperature range |
-40ºC ~ +55ºC |
| Material |
Precise casting aluminum alloy |
| Weight |
<10kg |
| Input / Output |
| Power supply |
AC220 ±10% 50/60Hz |
| Network interface |
1×10Base-T/100Base-TX,RJ45 |
| Control interface |
RS422 |
| Environmental Adaptability |
| Operating Temperature |
-40°C to +65°C |
| Windproof |
Yes |
| House |
nano - treated water droplets naturally drip |
| Constant temperature protection |
Support |
| Constant humidity protection |
Support |
| Protection grade |
IP66 |
| Physical |
| Weight with seal house |
Approx 35kg |
| Packing and Warranty |
| Standarding accessories packing |
hard case, user's manual, video cable, power cable |
| Warranty |
1 year warranty |
Note: *- Technical information is subject to change without notice. ** -Depending on the region of sale.
*** - Option add thermal camera. |
