11km Man 30~600mm Coaxial Zoom Thermal imaging camera

Model No.︰

CS600

Brand Name︰

TianYing

Country of Origin︰

China

Unit Price︰

-

Minimum Order︰

5 pc

Share on:

Product Description

China TianYing CS600 30~600mm coaxial zoom cooled thermal imaging cameras were engineered to aim and align targets, deliver target do not move when zoom in -45°C  to +70°C, especially designed for use by high accuracy tracking, measuring and aligning target system integrator.

The CS600 utilize maximum sensor range performance by using proprietary continuous fields-of-view lens, highly sensitive sensors and unique video enhancement algorithms. that offer 18 degrees FOV, high reliability, sharp clarity image, recognition human 7km and detection human 11km - 640x512.

The camera features a 20x accurate coaxial zoom long range high reliability cooled thermal camera with very compact size, that is very convenient alone use and easy integrated into airborne, maritime, and land tactical platforms system.

CS600 extreme long range surveillance coaxial zoom thermal imaging camera Recommended Use:
1. Long range accuracy measurement aiming.

2. Long range accuracy weapon sight.

3. Long range accuracy defense.

4. Long range accuracy target tracking.

5. Anti-missile.

CS600 long range surveillance coaxial zoom cooled thermal cameras Specifications:

Model C600
Detector Parameters
Detector type Cooled FPA HgCdTe
Pixels 640x512 15μm×15μm
Spectral Range 3.7μm~4.8μm
NETD ≤ 25mK ( F/4.0 6ms typical < 20mK)
Cooling type Stirling Cycle Cooling
MTTF >10000 hours
Optics Parameters
Focus Length 30mm to 600mm.
FOV 0.91° x 0.73° ~ 18.3° x 14.7°
Through-zoom boresight ≤ 5 pixels deviation (typical 3pixels), option other acuracy.
Image Presentation
Analog video output PAL, option NTSC.
Digital video output CameraLink
Frame frequency 30Hz, option 50Hz/60Hz,100Hz/120Hz.
Brightness Contrast Auto/Manual
Polarity; BH/WH
Interfaces
Command and control RS422, option RS232
Power Parameters
Power supply 24V to 36V DC
Consumption ≤15W at 25ºC
Environmental Parameters
Operating temperature -40ºC~+60ºC
Storage temperature -50ºC~+70ºC
Quality GJB150
Physical Parameters
Weight  ≤13kg
Length ≤ 550mm, option ≤ 420mm
Color Black
Range Performance
Detection/ recognition human range Approx 11 km / approx 7km.
Detection/recognition 3m x 6m vehicle Approx 16 km / approx 14km.
* - Note: *Technical information is subject to change without notice.
** - Depending on the region of sale.

When working range is more than 15km, then theory range data will decline rapidly, this is why 750mm, 1000mm and 1200mm focus 640x512 cooled thermal cameras detect range that is approx. 20km(vehicle) in normal weather condition, we already test 750mm focus, 1000mm focus, 1200mm focus, and 1650mm focus 640x512 cooled thermal camera working distance.



Custom WFOV to Ultra Extreme NFOV Long Range cooled thermal MWIR mid wave lenses are available, including 300mm diameter big lens.



Product Image

thermal camera with pan/tiltthermal camera with pan/tilt

TianYing thermal camera 640x512 image and 1024x768 imageTianYing thermal camera 640x512 image and 1024x768 image



TianYing electric optical turret system thermal camera auto tracking airplane.



TianYing 1024x768 thermal camera see vehicle and mountain.



TianYing 320x256 75mm f1.0 lens thermal imager see person 600m, 850m and 900m.



TianYing 640x512/640x480/1024x768 continuous focus uncooled thermal camera search target.
