15km Man 55~1100mm Coaxial Zoom Thermal imaging camera

Model No.︰

CS1100

Brand Name︰

TianYing

Country of Origin︰

China

Unit Price︰

-

Minimum Order︰

3 pc

Share on:

Product Description

China TianYing CS1100 55~1100mm coaxial zoom cooled thermal imaging cameras are engineered to aim and align targets, deliver target do not move when zoom in -45°C to +70°C, especially designed for use by high accuracy tracking, measuring and aligning target system integrator.

The CS1100 utilize maximum sensor range performance by using proprietary continuous fields-of-view lens, highly sensitive sensors and unique video enhancement algorithms, that offer 10 degrees FOV, high reliability, sharp clarity image, recognition human 9km and detection human 15km - 640x512.

The camera features a 20x accurate coaxial zoom long range high reliability cooled thermal camera with very compact size, that is very convenient alone use and easy integrated into airborne, maritime, and land tactical platforms system.

CS1100 extreme long range surveillance coaxial zoom thermal imaging camera Recommended Use:
1. Long range accuracy measurement aiming.

2. Long range accuracy weapon sight.

3. Long range accuracy defense.

4. Long range accuracy target tracking.

5. Anti-missile.

CS1100 extreme long range surveillance coaxial zoom cooled thermal cameras Specifications:

Model CS1100
Detector Parameters
Detector type Cooled FPA HgCdTe
Pixels 640x512 15μm×15μm
Spectral Range 3.7μm~4.8μm
NETD ≤ 25mK (25ºC, F/5.5)
Cooling type Stirling Cycle Cooling
MTTF >10000 hours
Optics Parameters
Focus Length 55mm to 1100mm.
FOV 0.5° x 0.4° ~ 10° x 8°
Through-zoom boresight ≤ 5 pixels deviation (typical 3pixels).
Image Presentation
Analog video output PAL, option NTSC.
Digital video output CameraLink
Frame frequency 30Hz, option 50Hz/60Hz,100Hz/120Hz.
Brightness Contrast Auto/Manual
Polarity; BH/WH
Interfaces
Command and control RS422, option RS232
Power Parameters
Power supply 24V to 36V DC
Consumption ≤15W at 25ºC
Environmental Parameters
Operating temperature -40ºC~+60ºC
Storage temperature -40ºC~+70ºC
Quality GJB150
Physical Parameters
Weight  ≤17kg
Length ≤ 634mm
Color Black
Range Performance
Detection/recognize human range Approx 15 km/ approx 9km.
Detection/recognition 3m x 6m vehicle Approx 21 km/ approx 18km
* - Note: *Technical information is subject to change without notice.
** - Depending on the region of sale.

When working range is more than 15km, then theory range data will decline rapidly, this is why 750mm, 1000mm and 1200mm focus 640x512 cooled thermal cameras detect range that is approx. 20km(vehicle) in normal weather condition, we already test 750mm focus, 1000mm focus, 1200mm focus, and 1650mm focus 640x512 cooled thermal camera working distance.



Custom WFOV to Ultra Extreme NFOV Long Range cooled thermal MWIR mid wave lenses are available, including 300mm diameter big lens.



Product Image

16km Man 55~1100mm Coaxial Zoom Thermal imaging camera16km Man 55~1100mm Coaxial Zoom Thermal imaging camera

1100mm Thermal imaging camera for security and surveillance1100mm Thermal imaging camera for security and surveillance

C1100 110~1100mmm continuous zoom cooled thermal camera see human 10km

Custom WFOV to Ultra Extreme NFOV Long Range cooled thermal MWIR mid wave lenses are available, including 300mm diameter big lens.
