4MP 750mm cctv 25W IR 2km~3km laser night vision camera

Model No.︰TY-P15

Brand Name︰TianYing

Country of Origin︰China

Unit Price︰US $ 12000 / pc

Minimum Order︰5 pc

Inquire Now

Product Description

China TianYing TY-P15 IP PTZ surveillance 4mp 750mm CCTV 25W IR 2km~3km laser night vision camera is the best low-cost day / night long range observation system without using a thermal camera.

The PTZ 2km~3km laser night vision camera is including 4MP 12.5~750mm zoom electronic image stabilization CCTV camera, 25W homogenization balanced light IR laser illuminator, multiple protections 0.1° repeatability accuracy pan/tilt, and integrated protective housing. The system features high resolution image, real performance, stable reliable operation and reasonable cost.

Mounted on a stabilized base, this 2km~3km laser night vision PTZ camera system provides no blind spot undetected with a 24/7 situational awareness, mainly used for forests, border and coastal defense, grasslands, ports, military fortresses etc.

In addition, the TV camera's features allow users to reject false and exaggerated propaganda, such as backhaul focal length 700mm say this is 860mm, 945mm, 1000mm or 1200mm lens. At beyond 15km visibility, the 30km mountain image civil security camera with no detail is at most the level of the 750mm camera.

Security surveillance PTZ 4MP 750mm CCTV 2km~3km night vision camera specifications:

Model	TY-P15
Performance
Daytime	≥12km (can be 14km) for human
Night	≥2km (can be 3km, even over 3km) for human
Identify the person's face	Approx 1.6km
Read the driving license plate	Approx 1.6km
Day Night TV Camera
Sensor	1/1.8 inch COMS 4 Megapixel 2688 x 1520 25Hz/30Hz.
Signal to noise ratio	≥55dB (AGC OFF)
Coding format	H.265 / H.264，H.265+/H.264+, HDMI/SDI/CVBS/RJ45
Video bit rate	32kbps~32Mbps
Storage Capabilities	Micro SD/SDHC /SDXC card (256 GB)
Network Protocol	ONVIF, HTTP, RTSP, RTP, TCP, UDP etc
Min. Illumination	Color: 0.005Lux f1.5; B/W: 0.001Lux f1.5
Image adjustment	Brightness, contrast, saturation, sharpness, chroma etc
Image enhancement	Strong light suppression, Exposure mode, BLC, ROI, 3D NR etc
Wavelength range	400nm ~ 950nm (0.4~0.7μm daylight, 0.7μm~0.95μm NIR)
Field of View (2.9um-LAN),°	Approx 35.7° x 20.2° ~ 0.59° x 0.33°
Focal Length	12.5~750mm continuous optical zoom.
Aperture	F6~ F11
Close-up distance, m	Approx 5m(can be 1m)
Image stabilization	Support
Electronic defog	automatic, manual, manual mode defog level can be adjusted
Optics defog	Support
Serial command	Support rear focal adjustment, specify focal length etc function
AI detection and alarm	Support area intrusion, cross-border,sound detection, behavior analysis etc
AI recognition	Can accurately identify human figures, vehicles and other targets
Operating temperature	-25ºC ~ +60ºC
Laser Illuminator
Wavelength	808nm
Power	25W
Light source change mode	Laser and lens angle linkage, manual
Homogenization balanced light	Yes
Operating temperature	-40ºC ~ +35ºC
Pan/Tilt
Random error of angular accuracy	0.1°
Direction range	azimuth:360° continuous; elevation:+10°~-70°
Directing speed range for azimuth	0.01°/s to 15°/s
Directing speed range for elevation	0.01°/s to 15°/s
Presets	200 presets, supporting zoom focus presets memory
Cruise	4 cruising paths, each path can set 16 presets
Communication protocol	Pelco-D
Operating temperature range	-40ºC ~ +55ºC
Material	Precise casting aluminum alloy
Weight	<10kg
Input / Output
Power supply	AC220 ±10% 50/60Hz
Network interface	1×10Base-T/100Base-TX,RJ45
Control interface	RS422
Environmental Adaptability
Operating Temperature	-40°C to +65°C
Windproof	Yes
House	nano - treated water droplets naturally drip
Constant temperature protection	Support
Constant humidity protection	Support
Protection grade	IP66
Physical
Weight with seal house	Approx 35kg
Packing and Warranty
Standarding accessories packing	hard case, user's manual, video cable, power cable
Warranty	1 year warranty
Note: - Technical information is subject to change without notice. * -Depending on the region of sale. *** - Option add thermal camera.
